APS Series-Azimuthal Gamma
| Azimuthal Gamma | |
|---|---|
|
Full size: 4.75″，6.75″，8.0″ |
Temperature: 150℃，175℃ |
|
Pressure: 20,000Psi，25,000Psi |
Resistant to harsh environments: CO, CO2, H2S |
|
Measurement accuracy: ±3% @ 100API |
Measurement range: API calibrated 0-800 API |
|
Drogue detection depth: 6in (152mm) |
Sampling frequency: 5s-60s programmable |
|
Number of probes: 3 or 4 |
Sector Bin: Real-time 1-8, Storage 1-16, Programmable |
|
Probe: Sodium Dianide Crystal Scintillation Counter + Photoelectric Booster Tube |
Slurry: oil-based, water-based, synthetic, salt water |
| Scope of Application | |
|---|---|
|
Determination of lithology with drilling |
Determination of void pressure (resistivity, acoustic) |
|
Geosteering |
Determination of entering or leaving the stratigraphy |
|
Determination of stratigraphic dip |
Selection of casing depth |
|
Alternative to conventional cable logging |
|
